Multiconductor®
7-pole continuous conductor system from Akapp-Stemmann
Download our brochure
Take a look at our brochure today and find out more about our products
| Feature | Specification |
|---|---|
| Conductor types | CU35, CU50, CU80, CU125, CU160 (electrolytic copper) |
| Max conductor length | Unlimited (extremely long lengths are achieved with expansion joints) |
| Voltage rating | Up to 690V (CE/CCC), 600V (UL) |
| Protection class | IP44 (IP23 without seal) |
| Temperature range | -20°C to +80°C |
| Max speed | Up to 250 m/min, depending on conductor and trolley type |
| Housing material | Rigid unplasticised PVC – red/white |
| Mounting options | Sliding hangers, fixed clamps, various support brackets |
Why Choose the Multiconductor®?
The Multiconductor® has exceptional benefits and features
- Continuous flat copper conductors – Supplied in joint-free rolls for uninterrupted power transmission
- High current capacity – Available in 35A, 50A, 80A, 125A, 160A, 250A and 320A options to meet varied power demands
- Control and data transfer – The combination of continuous copper and carbon brushes provides control and data transfer for critical equipment
- Virtually maintenance-free – No conductor joints reduce brush wear and lower carbon deposit levels
- Safety-first design – IP44 (with seal), IP23-rated (without seal) PVC housing is self-extinguishing, impact-resistant, and ensures high personnel protection.
- High travel speeds – Up to 250 m/min. Higher speeds rates on request
Available Accessories
- Collector trolleys – For standard or high-speed travel, with options for curves and expansion joints
- Transition boxes & Towing arms (trolley accessories) – Safe and easy connection to the apparatus
- Feed boxes – End and line feed boxes in multiple configurations (M32, M40, M63 glands)
- Expansion joints & Joint clamps – Allow for flexible long-distance installations
- Curved tracks – Horizontal and vertical
- Installation tools – Copper pulling cassette, copper drawing block, guide strips, straightener, and pressing tool for sealing strips
Service & Support
Metreel offers full support from specification and supply through to installation and maintenance. Our team can advise on the best configuration, assist with system design, and even carry out installation via our experienced engineers.
With Metreel, you’re partnering with a fully accredited and insured team with a proven track record in delivering durable, high-spec power supply systems for industrial environments.
