ProDuctor®
4, 7 or 10-pole continuous copper conductor system from Akapp-Stemmann
Download our brochure
Take a look at our brochure today and find out more about our products
| Feature | Specification |
|---|---|
| Conductor types | CU50, CU80, CU125, CU160, CU200 (electrolytic copper) |
| Max conductor length | Long lengths |
| Voltage rating | Up to 690V (CE/CCC), 600V (UL) |
| Protection class | IP2XB, IP44 (IP23 without seal) |
| Temperature range | -30°C to +60°C |
| Max speed | Up to 500 m/min, depending on the conductor and trolley type |
| Housing material | Rigid unplasticised PVC, red |
| Mounting options | Various brackets |
Why Choose the ProDuctor®?
The ProDuctor® has numerous impeccable features, making it the ultimate conductor design
- Continuous flat copper conductors – No jointed connections needed
- High current capacity – Available in 50A, 80A, 125A, 160A and 200A options to meet varied power demands
- Simple installation – Individual housing lengths easily connect with joint connection pins. No screwing or drilling needed
- No expansion issues – Each copper conductor lies separately in each channel for easy expansion and contraction
- Safety-first design – IP2XB PVC housing is self-extinguishing, impact-resistant, and ensures high personnel protection
- Extendable – Extendable until the maximum slots are reached, perfect for accommodating changing operational needs
- Low maintenance – Requires little maintenance, ensuring maximum return on investment (ROI)
Available Accessories
- Collector trolleys – For standard or high-speed travel
- Feed boxes – End and line feed boxes in multiple configurations (M32, M40, M63 glands)
- Transfer guide sectors – For aisle changing cranes
- Installation Tools – Copper pulling cassette, copper straightener, and positioning tool
Service & Support
Metreel offers full support from specification and supply through to installation and maintenance. Our team can advise on the best configuration, assist with system design, and even carry out installation via our experienced engineers.
With Metreel, you’re partnering with a fully accredited and insured team with a proven track record in delivering durable, high-spec power supply systems for industrial environments.
