Hoists sit at the centre of most overhead lifting systems, whether that is a single jib crane in a small workshop or a full overhead crane installation across a production line. Two of the most common types are the wire rope hoist and the chain hoist, and choosing between them affects lifting capacity, headroom, duty cycle and long term running cost.
This guide from Metreel explains how each works and how to choose the right one for your application.
What Is a Wire Rope Hoist?
A wire rope hoist uses a steel wire rope wound around a drum to raise and lower a load. As the drum turns, the rope winds on or off in a controlled, even layer, which allows wire rope hoists to lift heavier loads smoothly and at higher speeds than most chain hoists. This makes them a common choice for overhead cranes handling large or continuous loads, particularly in heavy industrial and manufacturing environments.
What Is a Chain Hoist?
A chain hoist uses a load chain running through a pocket wheel rather than a wire rope on a drum. Chain hoists are generally more compact, lighter and better suited to lower headroom applications, which makes them a popular fit for jib cranes and workstation cranes where space above the lift point is limited. Metreel supplies a full range of chain hoists, including hook suspension and low headroom options.
Key Differences Between Wire Rope and Chain Hoists
- Lifting capacity: wire rope hoists typically handle heavier loads and are more common at higher capacities.
- Lifting speed: wire rope hoists generally lift faster, which matters for high frequency or continuous duty operations.
- Headroom: chain hoists usually need less headroom, making them better suited to lower ceiling heights.
- Duty cycle: wire rope hoists tend to handle continuous or heavy duty cycles more comfortably over time.
- Maintenance: chain hoists are generally simpler and cheaper to maintain, while wire rope hoists need regular rope inspection.
Which Should You Choose?
The right choice depends on the application rather than one hoist type being better than the other. For heavier loads, continuous duty cycles or faster lifting speeds, a wire rope hoist fitted to an overhead crane or gantry crane is usually the stronger fit. For lighter, more frequent lifts in a confined space, such as a jib crane positioned over a single workstation, a chain hoist is often the more practical and cost effective option.
Safety and Compliance
Whichever hoist type you choose, it must be correctly rated and inspected for the load it is lifting. Understanding safe working load and the difference between WLL and SWL is essential before specifying any hoist. It is also worth reviewing crane hook types and safety latches, since the hook fitted to a hoist plays a direct role in how safely a load is secured.
Hoists From Metreel
Metreel supplies both wire rope and chain hoists as part of a wider range of mechanical handling equipment, including overhead cranes, jib cranes and workstation cranes. To discuss which hoist type suits your application, view our full hoists, balancers and winches range or call our team on 0115 932 7010.
